axis ax0-100 practice test

Which of the following allows customer to access between 2-4 channels of live and online stored
video at any time?

• A. AXIS Camera Station
• B. AXIS Video Hosting System (AVHS)
• C. AXIS Camera Management
• D. AXIS Media Control

Axis recommends shielded cables for outdoor installations primarily to ensure

• A. Image quality.
• B. Surge protection.
• C. Life time of cable installations.
• D. Conformity with SMPTE standard.

In setting up PTZ control for an Axis encoder, it's very easy to overlook a very important step in the
configuration process. After properly connecting the communication wires to the encoder, the next
recommended step in the setup is:

• A. Downloading the correct Device ID from the Axis website
• B. Setting the Baud Rate to match the analog PTZ' s
• C. Setting the Device ID to match the analog ID
• D. Uploading the correct PTZ driver

Which setting would best adjust a hard yellow tint as shown in the pictures below?

• A. Image contrast
• B. White balance
• C. Color saturation
• D. Image brightness

Which is an impact on cameras that are operating above their specified temperature limit?

• A. Noise is increased
• B. Frame rate is reduced
• C. Light sensitivity is decreased
• D. Resolution is reduced

Which technology can a Video Management Software (VMS) partner incorporate to reduce the
impact on recorded video during server maintenance?

• A. Local storage at the camera
• B. Meta data stream
• C. AXIS Camera Application Platform (ACAP)
• D. SNMP

A customer has a lot of motion blur on recordings from a fixed camera. What would be the most
likely setting to address the blurring?

• A. Gain level
• B. Brightness
• C. Backlight compensation
• D. Shutter speed

Which statement is true regarding H.264 and Motion JPEG?

• A. The highest bandwidth savings using H.264 compared to Motion JPEG is at high frame rates
• B. Bandwidth savings using H.264 has nothing to do with frame rate, only scene complexity
• C. Bandwidth savings using H.264 has nothing to do with frame rate, only Group of Video (GOV) setting
• D. The highest bandwidth savings using H.264 compared to Motion JPEG is at low frame rates

Which of the following will allow a customer to have a PTZ camera automatically change between
three predefined positions?

• A. Configure the camera's I/O ports to control the preset positions
• B. Use the Guard Tour capability to switch between the preset positions
• C. Switch between the predefined positions using a joystick
• D. Use the auto tracking capability to switch between the preset positions

In a network surveillance installation, the purpose of a router is to

• A. Forward the video stream between networks.
• B. Forward the video stream to the correct receiver within a network.
• C. Separate audio and video traffic to reduce audio latency.
• D. Separate the video stream from the camera control signaling.
